PCB Assembly (PCBA) Services in Shenzhen
Turnkey SMT & through-hole assembly — prototype to volume, ≥99.5% first-pass yield, AOI · X-ray · ICT.
BELI Technologies provides turnkey PCB assembly (PCBA) in Shenzhen — from small-batch prototypes to volume production. Our SMT lines place components from 0201/01005 up to 0.4 mm pitch BGAs at ±0.03 mm accuracy, backed by AOI, X-ray and ICT inspection.
Our PCB assembly service covers everything from prototype to mass production. We provide comprehensive DFM reports before assembly begins, ensuring quality from the start. Our advanced SMT lines handle the smallest components with exceptional precision.
From small batch prototypes to high-volume production, BELI ensures consistent quality through rigorous incoming material control, automated inspection, and comprehensive testing.
The partner assembly lines we use handle boards from 45 × 45 mm up to 680 × 500 mm, placing components as small as 0201/01005 and BGAs down to 0.4 mm ball pitch at ±0.03 mm precision, with a total capacity of roughly 52 million placements per month. Solder paste inspection (SPI), nitrogen reflow, and wave or selective soldering for through-hole parts keep first-pass yield at or above 99.5%.
We support both turnkey and consignment models with no fixed ratio, so you can hand off the full BOM or supply your own parts. Quick-turn prototype assembly takes 48 hours with no minimum order quantity, while turnkey orders including component sourcing typically take 2 to 3 weeks. Value-added options include conformal coating, potting, and complete box-build assembly.
Capabilities & Specifications
| Max PCB Size | 680 × 500 mm |
|---|---|
| Min PCB Size | 45 × 45 mm |
| Board Thickness | 0.4 – 5 mm |
| Min Component Size | 0201 / 01005 |
| Component Max Height | 25 mm |
| Min Lead Pitch | 0.35 mm |
| Min BGA Ball Pitch | 0.4 mm |
| Placement Precision | ±0.03 mm |
| Packages | DIP / SOP / QFP / PGA / BGA / CSP |
| Soldering Standard | J-STD-001 (requirements for soldered assemblies) |
| Workmanship Standard | IPC-A-610J (acceptability of electronic assemblies) |
| First-Pass Yield | ≥ 99.5% |
Need the full picture? See our complete PCB & SMT manufacturing capability specifications.
Attach your Gerber & BOM in the form — quote within 24 hours, 7 days a week
Our Process
DFM & Sourcing
Assembly DFM review and component procurement (turnkey or consignment).
Solder Paste & SMT
Stencil printing, SPI, and high-speed SMT placement.
Reflow & Through-Hole
Nitrogen reflow soldering plus wave/selective soldering for THT.
AOI & X-ray
Automated optical inspection and X-ray for BGA/QFN joints.
ICT / Functional Test
In-circuit and functional testing to verify every board.
Value-Add & Ship
Optional conformal coating, potting and box-build before shipment.
Why BELI
- Turnkey from BOM to box-build — sourcing, assembly and test in one place.
- ≥99.5% first-pass yield with AOI, X-ray and ICT on every order.
- Handles fine-pitch SMT down to 01005 and 0.4 mm BGA.
- No MOQ for prototypes — scale to volume with the same line.
- Minimum 12-month workmanship warranty — defects traced to our manufacturing are remedied at our cost.
“The SMT assembly quality exceeded our expectations. Zero defects across 5,000 boards in our first batch. Their AOI and X-ray inspection process is thorough and their engineering team is always responsive.”
Ordering & Terms
| Minimum order | No MOQ for prototypes; small batches scale to volume on the same lines |
|---|---|
| Payment | T/T bank transfer, PayPal, major credit cards, Western Union. Sample and small orders prepaid; production orders 30% deposit / 70% before shipment. Every quotation states its payment terms explicitly |
| Incoterms | EXW and FOB Shenzhen are the most common; DAP and DDP quoted on request — tell us your preferred term with your RFQ |
| Warranty | Assembled boards carry a minimum 12-month workmanship warranty. Defects traced to BELI manufacturing are remedied at BELI's cost — rework or replacement, refund, or local repair with costs covered |
